Description
DCNM-HDMIC High directive microphone
Commercial Type No.: DCNM-HDMIC
Product No.: F.01U.269.132

- Discrete microphone for user convenience
- High directive response
- Low susceptible for mobile phones
- Ultra low noise
- Freedom of movement

Details :
Power supply : 5 VDC
Power consumption : 0.1 W
Bandwith : 100 Hz – 15 kHz according IEC 60914
Dynamic range : > 96 dB
Nominal input : 80 dB SPL
Maximum input : 110 dB SPL
Equivalent noise : 12 dB SPL
Mounting : Plug and fasten into DICENTIS devices.
Dimensions (H x W x D) : 108 x 21.5 x 60 mm(4.25 X 0.85 x 2.36 in)
Weight : 0.035 kg (0.077 lb)
Color : Traffic black RAL 9017Pearl light grey RAL 9022
Operating temperature : 0 ºC to +45 ºC(32 ºF to +113 ºF)
Storage and transport temperature : -20 ºC to +70 ºC(-4 ºF to +158 ºF)
Relative humidity : < 95 %, > 5%
